Boat is hard to turn right, easy to the left


  • Please log in to reply
7 replies to this topic

#1 Chris Christensen

Chris Christensen
  • Members
  • 53 posts
  • Location:Sparta, Michigan

Posted 07 May 2011 - 01:18 PM

I have a 1985 Chaparral 187xl with the 3.7L / alpha one drive. When turning right, I must really apply a lot of pressure to make the turn and to stay in the turn. Turing to the left is easy. It behaves in this manner at higher speeds. Any help is appreciated.
1985 Chaparral 187XL
Mercruiser 3.7

Sparta, MI 49345

"Take advantage of the warmer days (45 degrees or more) when you get them."

#2 Weekend At Bernie's

Weekend At Bernie's
  • Members
  • 449 posts
  • Location:Jacksonville, FL

Posted 07 May 2011 - 03:06 PM

Is it the actual steering wheel resisting a right turn or does the boat just not follow the steering wheel when turned to the right? Maybe too much weight bias on the port side. Does the boat list in either direction?

2006 Signature 310



#3 Brian S

Brian S
  • Members
  • 619 posts
  • Location:Canton, Michigan

Posted 07 May 2011 - 03:43 PM

Which type of anode do you have on the drive unit. IF you have the style with the skeg sticking down in front of the prop it needs to be adjusted to compensate and make turning effort equal (non power steering boat). It should be turned to the left a bit. Power steering boats don't need one so you will see some boats with just a flat anode.
2004 204 SSi w/ 5.0l EFI & Alpha 1 gen2
2013 F150 Super Crew. Eco Boost

#4 Chief Plasma

Chief Plasma

    Davy Jones... "What's in your locker?"

  • Members
  • 4,073 posts
  • Location:Nashville, TN

Posted 08 May 2011 - 11:52 PM

The main question... is does it do this when your stopped at idle??
and.. do you have power steering?

1995 2130 SS Chaparral 5.7 with Yamaha Stern Drive.
2008 Dodge Ram 2500 4wd Heavy Duty w/ Crew Cab 5.7L Hemi (a beast!)


>>Smart Tab Install<<.......... >>My Boat Bookmarks<<


#5 Chris Christensen

Chris Christensen
  • Members
  • 53 posts
  • Location:Sparta, Michigan

Posted 12 May 2011 - 01:27 PM

Is it the actual steering wheel resisting a right turn or does the boat just not follow the steering wheel when turned to the right? Maybe too much weight bias on the port side. Does the boat list in either direction?


When the boat is at no wake speed the controls behave correctly and smoothly (except for a little play in the wheel), when I get on plane is when I really notice the difficulty in steering to the right. I get this if I am on the boat alone on the starboard side or if the boat is balanced with other people. If I am on the boat alone, the boat does list to the starboard side.

This boat has no power steering. It has a trim tab with a skeg. I will try to adjust the trim tab to see if it makes a difference.
1985 Chaparral 187XL
Mercruiser 3.7

Sparta, MI 49345

"Take advantage of the warmer days (45 degrees or more) when you get them."

#6 Shepherd

Shepherd

    First Sea Lord

  • Validating
  • 4,120 posts
  • Location:Gananoque, Ontario

Posted 12 May 2011 - 08:53 PM

The next time you have the impeller changed, I'd install Mercury part # 822777a2. This is the high performance magnesium anode that will allow you to run whatever prop you desire (some props and pitches will hit the standard fin anode) while still providing a slightly larger fin to help compensate for steering torque on your non p/s engine. I opt for this anode when I'm changing the anode above the prop on all Alpha and Bravo 1 drives as it has more material to be sacrificed vs. the flat anode version. On p/s models, I just place the fin straight back.

Irregardless of whether you change the anode on the next impeller change, I'd install a new anode bolt, Merc part # 10-32470. The 1990 and older style Alpha drives can only have the bolt changed when the drive is split, and the bolt over time likes to seize on. This scenario requires drilling the bolt and anode out to get the drive split apart in the first place. Alpha Gen II models can have a socket fit down the hole to remove the bolt.
The most important things in life aren't things.
Anthony J. D'Angelo

Posted Image Posted Image Posted Image

#7 sdillc

sdillc
  • Members
  • 148 posts
  • Location:SE Michigan

Posted 14 May 2011 - 06:55 AM

What Brian S said...
2005 Signature 290 "Sine Wave"
Twin Merc 5.0's with Alpha One's
GPYC - Detroit, MI.

Posted ImagePosted ImagePosted Image

#8 Scupper Guppy

Scupper Guppy
  • Members
  • 36 posts
  • Location:ESE of the Weed Eater factory, on Lake Mrah

Posted 14 May 2011 - 07:04 AM

Turn your trim tab to the right (starboard). this will make it easier to turn right (starboard).
